TO-247B-4L(N)
|
| |
.png) |
|
Symbol |
Dimension |
Symbol |
Dimension |
| Min |
Max |
Min |
Max |
| A |
4.83 |
5.21 |
c |
0.55 |
0.68 |
| A1 |
2.29 |
2.54 |
E |
15.75 |
16.13 |
| A2 |
1.91 |
2.16 |
D |
23.30 |
23.60 |
| b |
0.60 |
0.80 |
D3 |
2.35 |
2.65 |
| b1 |
2.39 |
2.94 |
D4 |
2.50 REF |
| b2 |
1.07 |
1.6 |
D5 |
0.95 |
1.25 |
| b3 |
1.07 |
1.33 |
e |
(2.54 BSC) |
| S |
(6.15 BSC) |
e1 |
(5.08 BSC) |
| Q |
5.49 |
6 |
e2 |
(2.79 BSC) |
| φP |
3.51 |
3.65 |
L |
17.31 |
17.82 |
| D1 |
16.35 |
16.75 |
L1 |
3.97 |
4.37 |
| D2 |
3.68 |
5.1 |
E1 |
13.11 |
13.41 |
|
|
|
|
| |
|
|
